Extraline conveyor and processing belts/Prepress belts
| Product Construction/Design | |
| Conveying Side(Material): | polyurethane cross-linked (PUR) |
| Conveying Side(Surface): | Smooth |
| Conveying Side(Color): | Black |
| Traction Layer(Material): | Aramide fabric |
| Mumber of Fabrics: | 3 |
| Running Side/Pulley Side(Material): | Polyester (PET) fabric |
| Running Side/Pulley Side(Surface): | Impregnated fabric |
| Running Side/Pulley Side(Color): | Black |
| Technical Data | |
| Thickness: | 3.8 mm |
| Mass of belt (belt weight): | 4.3 kg/m2 |
| Pulley diameter (minimum): | 250mm |
| Tensile force for 1% elongation(k1% static)per unit of width | 70 N/mm |
| Tensile force for 1% elongation after relaxation(k1% relaxed)per unit of width | 45 N/mm |
| Admissible tensile force per unit of width: | 200 N/mm |
| Operating temperature admissible(continuous) | Min: -20℃ Max: 80℃ |
| Coefficient of friction on slider bed of pickled steel sheet: | 0.20[-] |
| Seamliss manufacturing width: | 3500mm |
| Hardness topside | Shore 90 |
| Product Characteristics | |
| Slider bed suitable: | Yes |
| Carrying rollers suitable: | Yes |
| Power turns,curved installations: | No |
| Low noise applications: | No |
| Antistatically equipped: | Yes |
| Metal detector suitabel: | Yes |
| Flammability: | No specific falmmability prevention property |
